E-504 Piezo Amplifier Module

High Power due to Energy Recovery, E-500 Piezo Controller System

  • Peak power 280 W
  • High continuous power of 100 W
  • Output voltage range -30 to 130 V
  • Module for E-500 piezo controller rack
  • Position control (optional)
  • Interface / display modules (optional)
E-504 Piezo Amplifier Module
Product Description Specifications Downloads Quote / Order

Power amplifier for low voltage piezo actuators

Peak currents to 2000 mA. 280 W peak power, average output power up to 100 W.

Energy recovery

Class-D switched amplifier with capacitor for energy recovery. Low influence of the application thanks to reduced heat dissipation.

The working principle of the E-504 series is particularly good for high dynamics scanning and switching applications. The E-505 is recommended for applications that require static position stability in a subnanometer range.

Application fields

Industry, automation. High dynamics scanning or switching applications.

Specifications

Datasheet

Datasheet E-504

Version / Date
2020-10-07
pdf - 644 KB
Version / Date
2020-10-07
pdf - 650 KB
Version / Date
2020-10-07
pdf - 704 KB
Version / Date
2018-10-24
pdf - 637 KB

Downloads

Datasheet

Datasheet

Datasheet E-504

Version / Date
2020-10-07
pdf - 644 KB
Version / Date
2020-10-07
pdf - 650 KB
Version / Date
2020-10-07
pdf - 704 KB
Version / Date
2018-10-24
pdf - 637 KB

Documentation

Documentation

Short Instruction PZ300

Housed Analog Piezo Electronics E-4xx, E-5xx, E-6xx, E-8xx

Version / Date
1.1.0 04/2021
pdf - 1 MB
Version / Date
1.1.0 04/2021
pdf - 1 MB
Documentation

User Manual PZ62

E-500 / E-501 Series Modular Piezo Controller: Chassis with power supply, amplifier modules (E-503, E-504, E-505, E-506, E-508), sensor and servo-control module (E-509), display and interface modules (E-515, E-517).

Version / Date
2013-07-11
pdf - 2 MB
English

Quote / Order

Ask for a free quote on quantities required, prices, and lead times or describe your desired modification. All products available online can be ordered directly.
